Climbing Structure 18, made of larch
Order number L6.51018
- kindergarten children
- schoolchildren
- supervised play areas such as kindergartens, schools, after-school programmes or similar
- public areas without supervision, such as playgrounds, parks or similar
Info
Attention! Technical modifications reserved. Request current assembly instructions for site dimensions.Designer
Richter Spielgeräte GmbHShare Climbing Structure 18, made of larch
Bevel cut
Vertical stand posts with bevelled end grain section as constructive wood preservation measure
Peeled white
Palisades peeled white means that bark, cambium and sapwood are removed, the natural shape of the trunk is preserved and can be experienced
Richter Hercules type rope
Richter Hercules type rope, a combination of galvanised six-strand steel cables and polyester yarn, diameter > 20 mm, laid and glued with very good abrasion resistance, strong sheathing even in the case of damage by puncturing
Aluminium rope pressing
Aluminium rope pressing, cylindrically pressed, with rounded ends
S-connectors
S-connectors Ø 8.1 mm, made of high-quality stainless steel, rounded
Profiled washer
Profiled washer for covering protruding screw heads according to standard, improved pressure distribution and protection against water. Impedes loosening the bolt
Adjustable
Adjustable two-piece bolt connection, easy to maintain, no projecting threads
Ground anchor
All parts used for anchoring to the ground are made of hot-dip galvanised steel or stainless steel
Distance fitting
Screw connection with distance fitting to avoid entrapment areas
Relief cut
Targeted relief cut as an effective measure against cracks caused by drying. The cut defines the position of the stress equalization in the trunk and minimises natural cracking
