Climbing Structure 17
Environmental friendly
Order number G6.51017
Climbing Structures made from hand-processed irregular round logs, can be integrated into a strongly nature-oriented environment due to their formal expressive character. Many children can play within a small space; Climbing Structures can even absorb the arrival of a large number of children who wish to play on it and incorporate all of them within a flowing play rhythm. Climbing Structures do not only allow for climbing, experiencing height, and for having a sensual experience with hands and feet, but they can also be used as a nice seat for relaxing and observing.
Environmental friendly foundation thanks to concrete-free sleeve foundations
The Robinia posts are placed into pre-fit steel rings and the space between the wood and the steel rings is filled with coarse and angular gravel (alternatively: sieved concrete rubble) and then backfilled and compacted.
- School children
- Young people
- Supervised play areas, such as kindergartens, schools, after-school programmes or similar
- Public play areas without supervision, such as playgrounds, parks or similar
Downloads
Info
Attention! Technical modifications reserved. Request current assembly instructions for site dimensions.Designer
Richter Spielgeräte GmbHShare Climbing Structure 17
Bevel cut
Vertical stand posts with bevelled end grain section as constructive wood preservation measure
Peeled white
Palisades peeled white means that bark, cambium and sapwood are removed, the natural shape of the trunk is preserved and can be experienced
Richter Hercules type rope
Richter Hercules type rope, a combination of galvanised six-strand steel cables and polyester yarn, diameter > 20 mm, laid and glued with very good abrasion resistance, strong sheathing even in the case of damage by puncturing
Aluminium rope pressing
Aluminium rope pressing, cylindrically pressed, with rounded ends
S-connectors
S-connectors Ø 8.1 mm, made of high-quality stainless steel, rounded
Profiled washer
Profiled washer for covering protruding screw heads according to standard, improved pressure distribution and protection against water. Impedes loosening the bolt
Adjustable
Adjustable two-piece bolt connection, easy to maintain, no projecting threads
Distance fitting
Screw connection with distance fitting to avoid entrapment areas
