Tower Combination 331, made of larch Tower Combination 331
Order number L2.33101
With this play combination, different opportunities for movement activities are offered within the smallest space. The tower with its sophisticated design is an attractive centre of a playground. Its small rooms offer security and protection or serve as a climbing object. There are several ways to reach the viewing platform and test your skills. The slide is an enjoyable way to descent to the ground.
- kindergarten children
- schoolchildren
- supervised play areas such as kindergartens, schools after-school programmes or similar
- public play areas without supervision such as playgrounds, parks or similar
- swimming pools without supervision, such as outdoor pools, adventure pools or similar
Info
Attention! Technical modifications reserved. Request current assembly instructions for site dimensions.Designer
Richter Spielgeräte GmbHShare Tower Combination 331, made of larch Tower Combination 331
Bevel cut
Vertical stand posts with bevelled end grain section as constructive wood preservation measure
Peeled white
Palisades peeled white means that bark, cambium and sapwood are removed, the natural shape of the trunk is preserved and can be experienced
Perforated
The earth / air zone of the wood is perforated by numerous small bore holes to ensure that the impregnating agent penetrates this particularly endangered zone
Core-free
Sawn-timbers core-free, thus decreasing occurrences of cracking and undesired changes in shape
Claddings
Claddings made of mountain larch (4 – 5 cm). Peeled white by hand, natural tree surface remains tangible and perceptible
Hardwood rungs
Climbing rungs made of hardwood (ash) Ø 4.2 cm, milled and mortised, secured against twisting, easy to grip and not cold for children to touch
Plywood
Plywood made of mountain larch, three-layer (3 cm) or five-layer (4 cm). High dimensional stability, waterproof, glued according to DIN EN 13353:2011
Richter Hercules type rope
Richter Hercules type rope, a combination of galvanised six-strand steel cables and polyester yarn, diameter > 20 mm, laid and glued with very good abrasion resistance, strong sheathing even in the case of damage by puncturing
Aluminium rope pressing
Aluminium rope pressing, cylindrically pressed, with rounded ends
S-connectors
S-connectors Ø 8.1 mm, made of high-quality stainless steel, rounded
Rope connection fixed
Fixed rope connection without dangerous openings. Screw connection adjustable and countersunk in the wood
Rope connection with joint
Close-fitting connection with joint, without dangerous openings, with sintered bush and adjustable screw connection
Adjustable
Adjustable two-piece bolt connection, easy to maintain, no projecting threads
Interlocking
Interlocking connection, with milled metal rings or serrated disc dowels, to reinforce the bolt connection under high loads transverse to the grain direction of the wood
Sintered bush
For all reciprocating movements we use sintered plain bearings which are self-lubricating in use and can easily be exchanged if necessary
Ground anchor
All parts used for anchoring to the ground are made of hot-dip galvanised steel or stainless steel
